Sinovision 4G Solar Panel PTZ Camera

SN-B6B20-4G-S

Main Feature

-   6pcs Array IR LED , 3.6mm lens 100 degree wide angle view ,15m IR vision

-  Support PIR motion detection,alarm push to mobile phone

-  Embed solar panel ,battery chargerd  Recharge dual power technology

-  Ultra low  power , 60uA  standby  , 170mA work

-   Built-in Micro SD card slot, Max 128G,3G/4G SIM Card Slot.

-   Plug-Play easy Setting (APP:MicroShare)

-   Built  in  Mic and  Speaker , support  two-way audio


  • Camera

    SN-B6B20-4G-S



    Image Sensor

    1/3 "Low illumination CMOS sensor



    Effective Pixels

    1920(H) x 1080(V), 2.0 Megapixels



    DSP+Sensor

    T20 +PS5250



    PIR

    10 On/Off PIR Detection, When someone invade the detection field, alarm notification will be push to Smart phone.



    Electronic Shutter Speed

    1/1s~1/30,000s



    Minimum Illumination

    Color: 0.005Lux@F1.6; B/W: 0.0005Lux@F1.6; 0Lux@F1.6 (IR on)



    S/N Ratio

    More than 55dB



    IR Distance

    Distance up to 30-50m (492ft)



    IR On/Off Control

    Auto/Manual



    IR LEDs

    6pcs Array IR LED



    4G



    Support Network

    FDD-LTE/TD-LTE/WCDMA/HSPA+/TD-SWCDMA/GSM/GPRS/EDGE



    Support Band

    B1/B3/B7/B20/B38/B39/B40/B41/B26



    Support Band of Frequencies

    FDD LTE Band7 / Band3/BAND1/BAND8



    TD-LTEBand38(2570-2620MHz)/Band39(1880-1920MHz)/Band40 (2300-2400MHz)Band41 (2496-2690MHz



    WCDMA/1900/2100/2600MHz



    TD-SCDMA Band34 (2010-2025MHz) / Band39 (1880-1920MHz)



    EDGE/GPRS/850/900/1800/1900MHz

    UMTS Band1 / Band2 / Band5 GSM 900 / 1800 / 1900 MHz

    Network Speed

    FDD-LTE/TD-LTE (4G) :150MBPS/50MBPS

    WCDMA(3G):21MBPS/5.76MBPS;TD-SCDMA(3G):2.8MBPS/2.2MBPS

    Protocol

    P2P,ONVIF2.4,TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UpnP,RTSP

    Video

    Compression

    H.265/H.264

    Streaming Capability

    2 Streams

    Resolution

    1080P(1920×1080)/ D1(704×576/704×480)/CIF(352×288/352×240)

    Frame Rate

    Main stream: 1080P/ (1~50/60fps)

    Sub stream1: D1/CIF(1 ~ 25/30fps)

    Sub stream2: 1080P/D1/CIF (1~25/30fps)

    Bit Rate Control

    CBR/VBR

    Bit Rate

    H.265/H.264: 448K ~ 8192Kbps

    Day/Night

    Auto(ICR) / Color / B/W

    Backlight Compensation

    BLC / HLC / D-WDR

    White Balance

    Auto, ATW, Indoor, Outdoor, Manual

    Gain Control

    Auto / Manual

    Noise Reduction

    Ultra DNR (2D/3D)

    Motion Detection

    Support

    Region of Interest

    Support

    Electronic Image Stabilization (EIS)

    Support

    Defog

    Support

    Audio

    Compression

    G726 ,G711,AAC,MP3,8K sampling rate,Support echo offset function

    Network

    SIM Card

    Support 3G 4G SIM Card

    Edge Storage

    NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 128GB

    Web Viewer

    IE, Chrome, Firefox, Safari

    Management Software

    Smart PSS, DSS, DMSS

    Smart Phone

    IOS, Android

    Interface

    Video Interface

    1 port(BNC, 1.0V[p-p], 75Ω)

    RS485

    1

    Audio I/O

    1/1

    Alarm I/O

    2/1

    Environmental

    Operating Conditions

    -40°C ~ 60°C (-40°F ~ +140°F) / Less than 95% RH

    Ingress Protection

    IP66

    Vandal Resistance

    N/A

    Casing

    Metal

    Power

    international standard , 2 x18650 ;Solar ;power supply
